On the basis of 135 Diesel Engine, G128 Diesel Engine is improved in combustion, block, crank, piston, connection rod and cooling and lubrication systems, and upgraded enormously in overall performance. It is another cost-efficient power choice for such engineering machine as Shovel Loader and dozer.
This engine is improved in start, cooling, lubrication, air intake&filtration and air pumping systems, reconfigures transmission system, simplifies conduits, adapts to dusty and severe environment like plateau and desert, is resistive to early abrasion and is more reliable to use.
Low Fuel Consumption
G128 Diesel Engine is economical in use and has a lower fuel consumption rate and better power performance in comparison with the models with the same displacement.
The Diesel Engine is more convenient to use and repair
|Bore × Stroke (mm)||135×150|
|Total Displacement (L)||12.88|
|Rated Power/ Speed (kW/r/min)||162/2200|
|Maximum Torque/ Speed (N.m/r/min)||≥810/1300-1400|
|Minimum Fuel Consumption Rate (g/kW.h)||218|
|Oil Consumption Rate (g/kW.h)||≤0.4|
|Overall Noise (LW) (dB(A))||≤98|
|Exhaust Emission||In accordance with GB17691-2001 Standard (Euro-I Standard)|
